Intro
I believe that you’ve already seen the filesystem of Windows. There are disks like C:, D:, E: and etc…
Linux has its own way to manage storage devices.
We’ll see how does it look and how to manage them, where are they stored.
For a hacker it is necessary to understand the file and storage device management system.
When you’re in your target system, you must understand what you’re working with and where to find confidential files.
We’ll begin with the directory /dev which stands for devices.
The Device Directory /dev
This directory contains files representing each attached device.
You can navigate to /dev directory and long list contents:
cd dev
ls -l
total 0
crw------- 1 root root 10, 123 Dec 31 10:12 acpi_thermal_rel
crw-r--r-- 1 root root 10, 235 Dec 31 10:12 autofs
drwxr-xr-x 2 root root 320 Dec 31 12:40 block
drwxr-xr-x 2 root root 80 Dec 31 11:16 bsg
crw------- 1 root root 10, 234 Dec 31 10:12 btrfs-control
drwxr-xr-x 3 root root 60 Dec 31 10:12 bus
drwxr-xr-x 2 root root 3400 Dec 31 11:16 char
crw------- 1 root root 5, 1 Dec 31 10:12 console
Each device on your system is represented by a file in the /dev directory, including devices you’ve probably never used or even knew existed.
In the list you can see sda1, sda2, sda3, sdb devices. These are the hard drives and its partitions, also a USB flash drive and it’s partitions.
brw-rw---- 1 root disk 8, 0 Dec 31 10:12 sda
brw-rw---- 1 root disk 8, 1 Dec 31 10:12 sda1
brw-rw---- 1 root disk 8, 2 Dec 31 10:12 sda2
brw-rw---- 1 root disk 8, 3 Dec 31 10:12 sda3
brw-rw---- 1 root disk 8, 16 Dec 31 11:16 sdb
brw-rw---- 1 root disk 8, 17 Dec 31 12:33 sdb1
How Linux Represents Storage Devices
Linux uses logical labels for drives that are then mounted on the filesystem. Sometimes same hard drive might have different labels at different times.
Newer Serial ATA (SATA) interface drives and Small Computer System Interface (SCSI) hard drives are represented as sda.
Drives are sometimes split up into sections known as partitions.
When systems have more than one hard drive, Linux names them serially by incrementing the last letter in alphabetical order. For example:
sda
sdb
sdc
Drive Partitions
We can also split drives into partitions. For example we can make few separate partitions in sda hard drive.
Partition labeling system:
sda1 - The first partition (1) on the first SATA drive (a)
sda2 - The second partition (2) on the first SATA drive (a)
sda3 - The third partition (3) on the first SATA drive (a)
This is useful when you want to share only certain files and give permissions to a certain group of users. Also there are many other reasons why this could be useful.
To check which partitions you have in your system and see the details about them you can use fdisk tool with -l flag.
fdisk -l
Device Start End Sectors Size Type
/dev/sda1 2048 1050623 1048576 512M EFI System
/dev/sda2 1050624 498116607 497065984 237G Linux filesystem
/dev/sda3 498116608 500117503 2000896 977M Linux swap
Disk /dev/sdb: 29.25 GiB, 31406948352 bytes, 61341696 sectors
Disk model: Cruzer Glide
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 512 bytes
I/O size (minimum/optimal): 512 bytes / 512 bytes
Disklabel type: dos
Disk identifier: 0x00000000
Swap acts like virtual RAM.
I also have external USB connected and you can see that it is called sdb.
Mounting and Unmounting
Most modern operating systems automount storage devices when they’re attached.
The term mount is from early days of computers. Storage tapes had to be physically mounted to the computer system. These are the days when computer size was half of a room.
Two main mount points in Linux are /mnt and /media
USB devices can be manually mounted at /mnt. (keep in mind that it can be mounted anywhere, but when you do so, the mounted device will cover the contents of the directory)
In some cases you need to mount drives manually so we’ll see how it’s done:
So I have my USB located at /dev/sdb (it’s located and visible at /devices directory)
Let’s mount it at the /mnt directory:
mount /dev/sdb1 /mnt
Now you can go to the /mnt directory and you’ll see that we see the contents of our files.
/mnt
file1
file2
file3
To unmount the drive we can write:
umount /dev/sdb1
Keep in mind that it’s umount and not unmount.
Monitoring Filesystems
Monitoring the state of filesystem is a necessary skill for a hacker.
To do so we can use df command (disk free). It’ll give us information about any hard disks or mounted devices.
df
Filesystem 1K-blocks Used Available Use% Mounted on
udev 3982012 0 3982012 0% /dev
tmpfs 804388 1488 802900 1% /run
/dev/sda2 243520884 23459860 207617992 11% /
/dev/sdb1 30655856 55808 30600048 1% /mnt
As you can see it also shows me my USB drive mounted on /mnt.
sda2 is my main disk and it breaks down as follows:
sd - SATA hard drive
a - First hard drive
2 - Second partition on that drive
